HIWIN Ball screw - FSS
ไฮวินบอลสกรู แบบ FSS
Ball screw - FSS
- F = แบบหน้าแปลน
- S = นัท 1 ลูก
- S = ท่อหมุนเวียนลูกปืนอยู่ในตัวนัท
- แบบหน้าแปลน 6 รูยึด
- สกรูขนาด 50 - 80 mm
- รับน้ำหนักได้ 25,410 - 55,620 kgf
รายละเอียดทางเทคเนิค (Specifications) HIWIN Ball screw - FSS
| Model | Shaftdia meter | Lead | Ball Dia. | Turn Circuits | Dynamic C | Static Co | D | L | F | T | E | X | Pmax | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kgf | KN | kgf | KN | kN | |||||||||||
| 2R50-40X2 | 50 | 40 | 12.7 | 2.8x2 | 25410 | 249.0 | 72310 | 708.6 | 115 | 189 | 165 | 32 | 140 | 14 | 61.8 |
| R63-32X1 | 63 | 32 | 15.875 | 2.8x1 | 21350 | 209.2 | 57470 | 563.2 | 140 | 173 | 190 | 32 | 165 | 14 | 49.9 |
| R63-32Y1 | 63 | 32 | 15.875 | 3.8x1 | 27770 | 272.1 | 78000 | 764.4 | 140 | 206 | 190 | 32 | 165 | 14 | 67.5 |
| R63-32Z1 | 63 | 32 | 15.875 | 4.8x1 | 33950 | 332.7 | 98520 | 965.5 | 140 | 238 | 190 | 32 | 165 | 14 | 85.0 |
| 2R63-40X2 | 63 | 40 | 12.7 | 2.8x2 | 28670 | 281.0 | 91350 | 895.2 | 130 | 189 | 190 | 32 | 160 | 18 | 84.4 |
| 2R63-40Y2 | 63 | 40 | 12.7 | 3.8x2 | 37290 | 365.4 | 123970 | 1214.9 | 130 | 229 | 190 | 32 | 160 | 18 | 115.0 |
| 2R63-50Z2 | 63 | 50 | 12.7 | 3.8x2 | 36710 | 360.7 | 122740 | 1202.9 | 130 | 275 | 190 | 36 | 160 | 18 | 113.9 |
| 2R70-40X2 | 70 | 40 | 12.7 | 2.8x2 | 30590 | 299.8 | 103750 | 1016.8 | 142 | 191 | 210 | 32 | 175 | 18 | 96.9 |
| 2R80-50X2 | 80 | 50 | 15.875 | 2.8x2 | 42770 | 419.1 | 142960 | 1401.0 | 175 | 233 | 250 | 40 | 210 | 22 | 134.0 |
| 2R80-50Y2 | 80 | 50 | 15.875 | 3.8x2 | 55620 | 545.1 | 194010 | 1901.3 | 175 | 283 | 250 | 40 | 210 | 22 | 183.6 |
